RST7.5F1.0-640-17
Rising
Infrared Manual Focus Lens Description:
Focal Length 7.5mm F1.0 Infrared Manual Focus Lens For 640x480-17um and 384x288-17um Detector.
8-12um Long Wave IR Germanium Lens Apply to Infrared Camera, Monitor Camera, Drone Monitor, Infrared Sights, Thermal Imager, etc.
Infrared lenses operate in three different wave bands: short, medium, and long. To ensure the best performance, the lens must be designed for its specific working band, and the materials used vary accordingly.
The infrared optical system is a passive detection system with clear functions. It can locate, detect, and track objects emitting infrared rays, even in the presence of background radiation and other disruptions. As a result, infrared lenses have many potential applications, including early warning detection, target search, and forest fire prevention.
Infrared Manual Focus Lens Parameters:
| Product Name | Infrared Manual Focus Lens |
| Focal Length | 7.5mm |
| F# | 1.0 |
| Material | Ge(Germanium), Chalcogenide, ZnSe(Zinc Selenide), ZnS(Zinc Sulfide), Si(Silicon) |
| Detector | 640x480-17um / 384x288-17um |
| Average Transmission | ＞85% |
| Circular FOV | (H)71.9°x(V)57°x(D)84.4° |
| Back Focus Distance | 16mm |
| Back Working Distance | 11mm |
| Dimensions | 47mm / 41mm |
| Focus Type | Manual Focus |
| Focus Range | 0.2m to infinity |
| Mount Type | M34x0.75 |
| Weight | 100g |
| Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -40℃ to +80℃ |
| External Coating | DLC / AR Coating Available |
Company Profile:
Our company specializes in manufacturing various instruments and equipment for the medical, life science, national defense and security, semiconductor, and industrial OEM markets. Our range of products includes infrared lenses, germanium lenses, night vision objective lenses, thermal camera modules, and more.
From designing optics to procuring materials to mass production, we are dedicated to optimizing the performance, cost, quality, and delivery time of our products.
To ensure the highest product quality, all items undergo rigorous machine testing and are confirmed with customers before being loaded and exported.
With the support of our professional engineers, efficient sales team, and competitive pricing, we have attracted customers from all corners of the globe. Our products are primarily sold in developed regions such as Southeast Asia, North America, Europe, Russia, Japan, South Korea, and others. They have garnered widespread acclaim and attention, establishing Rising as a trusted supplier for numerous OEM customers and research institutions worldwide.
Infrared Lens Factory Processing Equipment:
1. Inner carving test platform;
2. Microscope;
3. Opto Tech aspheric processing;
4. Polishing machine;
5. Thickness Gauge;
6. Ultrasonic Cleaner;
7. Workshop;
8. Interferometer;
9. High and low tempera ture test chamber;
10. High polishing machine;
11. Optical bench;
12. Raul milling;
13. Atomic force microscope;
14. Centralinstrument;
15. Hand Grinding and Polishing Machine;
FAQ:
